Feature:
- Most standard and popular model with capacity 1500/2000 kgs in light duty.
- Hand brake / drive hand pallet truck
- Easy 3 position control handle– Raise, Lower, Neutral.
- Easy manual zero correction.
- Gross /net weighing with the accuracy of 0.1-0.2%.
- Ergonomic powder coated handle, which is comfortable and convenient to operate.
- Fork lowering speed is controllable, operated by hand control and foot pedal.
- Integrated casting pump & welded pump.
- Error message in display.
- AAK provides reinforced fork frame for extra strength.
- We provide customized products as per client’s requirements.
- Factory calibration and user calibration
- Backlight indicator for read out
Wheels: Nylon wheel, Rubber wheel, Polyurethane wheel, Steel wheel
| SCALE HAND PALLET TRUCK- SPECIFICATION ( 2.0 TON ) | |||
| Description | Unit | EMPT 2.0T 560N/P -WS | EMPT 2.0T 695N/P -WS |
| Capacity | kg | Up to 2000 | |
| Fork dimensions | mm | 1500 × 500 × 1150 | 1620 x 695 x 1180 |
| Min.fork height | mm | 85 – 90 | |
| Max.fork height | mm | 195 – 200 | |
| Max. Lifting Hight | mm | ≥115 | |
| Fork Outside Distance | mm | 560 | 695 |
| Fork length | mm | 1150 | 1220 |
| Fork Width | mm | 160 | |
| Load roller | Std | ø80 x 70 | |
| Stering Wheel | mm | ø180 x 50 | |
| Frork Thickness | mm | 3.2 | |
| Pump | Std | DF/AC(Welded / Machined) | |
| Handle | Std | Mild Steel Powder Coated | |
| Structure | Std | Mild Steel Powder Coated | |
| Net Weight | KG | 115 | 122 |
| Material of Wheel | Std | Nylon / Polyurethane | |
