Feature:
Most standard and popular model with capacity 300/350 kgs.
- Convenient foot pedal arrangement.
- Rear wheels swivel 360 degrees.
- Standard clamping mechanism for grips all size steel, plastic and fiber drums.
- Standard tilting heavy duty gearbox for easy operation.
- For double clamp confirmation we are industrial belt for clamping.
- Structural heavy duty steel construction.
- Drum lowering speed is controllable, operated by hand control.
- Its Reduce time lost to personnel injuries and help increase your facility’s productivity.
- We provides drum lifter & tilter in two lifting height, 1200 & 1600 mm
- Easy use by all operators.
Wheels: Nylon wheel, Polyurethane wheel
| DRUM LIFTER & TILTER – SPECIFICATION | |||||
| Description | Unit | EMLT-3510 | EMLT-3514 | EMLT-3518 | EMLT-3528 |
| Capacity | Kg | 350 | |||
| Max. Lifting Height | mm | 1000 | 1400 | 1800 | 2800 |
| Max. Height (Drum Grab) | mm | 2150 | 2350 | 2700 | 3100 |
| Max. Height (Drum Grab) | mm | 1850 | 2050 | 2400 | 2050 |
| Overall Dimension ( L X W X H ) | mm | 1300 x 920 x 1850 | 1300 x 920 x 2050 | 1300 x 920 x 2400 | 1300 x 920 x 2050 |
| Front Wheel ( Dia x Width ) | mm | ø 180 x 50 | |||
| Stearing Wheel ( Dia x Width ) | mm | ø 180 X 50 | |||
| Drum Size | mm | ø 572 X 900 | |||
| Drum Tilt | Manual | ||||
| Net Weight | Kg | 170 | 190 | 220 | 240 |
| Material of Wheel | Std. | Nylon / PU | |||
